> PUNCHING MACHINE
Dual-working punching machine
- Plate Punching Machine
- Tube Punching Machine
- H-beam Punching Machine
- Angle/Channer Bar Punching
- Product description: Punch Pressure：60~300T
PRODUCT INTRODUCTION
Specifications
APEC hydraulic punching machine
Specifications
1. Max. punching capacity: dia 45mm* thi 35mm
2. Temperature Cooling system
3. CE certificate
Hydraulic Punching Machine
I. Features
*Full stroke adjustment.
*Low power inching and adjustable stroke.
*Large punch table with multi-purpose bolster removable table block for overhang channel/joist flange punching.
*Machines with very low maintenance requirements.
*Punch adaptors
*Swing away punch stripper unit
*Easy change punch holder
*Universal die bolster
II. Technical Parameter
|
Type |
P-60 |
P-90 |
P-120 |
P-160 |
P-200 |
P-250 |
|
Punch (diameter) (mm) |
dia 25×16 |
dia 30×20 |
dia 35×25 |
dia 40×30 |
dia 40×35 |
dia 45×40 |
|
Punch (pressure) (KN) |
600 |
900 |
1200 |
1600 |
2000 |
2500 |
|
Max stroke(mm) |
80 |
80 |
80 |
80 |
100 |
100 |
|
Stroke times (times/min) |
8 |
8 |
8 |
8 |
8 |
8 |
|
20mm stroke times(times/min) |
22 |
22 |
22 |
25 |
25 |
25 |
|
Motor power(KW) |
4 |
5.5 |
7.5 |
11 |
15 |
18.5 |
|
Depth of throat(mm) |
300 |
350 |
400 |
550 |
550 |
600 |
|
Net weight(Kg) |
1600 |
2000 |
3200 |
4200 |
5000 |
6200 |
